INFRARED RECEIVERS - RS232 - USB

Below are the models of infrared receivers by Celadon. There are 9 infrared receiver models available. Please see the descriptions below for each model of infrared receiver. Selecting the image will show further specifications for each receiver product.

Our infrared receivers can be programmed to work with your remote control, or, you can use one of our remote controls. Low volume remote controls (1+) are available.

Celadon can design new receivers, or modify one of our current designs, to best meet your application requirements.


RCV-5000 RS-232 Serial ASCII/HEX Output			Usage Examples
		The RCV-5000 RS-232 Serial Infrared Converter can be programmed for almost any IR input and any serial RS-232 output (ASCII/HEX) - See our current Device List for examples of custom RS-232 output. RCV-5000 receivers can be downloaded from a PC to install new firmware.	NEC Plasma TVs, Marantz Plasma TVs, Fujitsu Plasma TVs, Various Projectors, Computer Control (via serial port), almost any RS-232 controllable device (contact us for details) or see our current Device List

SC-38 Receiver			Usage Examples
		The SC Series receiver is a small profile infrared receiver. Small profile stereo jack output connector.	Discrete placement of infrared receiver used to control infrared capable equipment. Works with RCV-5000 Infrared Receiver



RCV-1000 Infrared Receiver			Usage Examples
		Small Profile Infrared Receiver with TTL level output. Receives all infrared signals in the 30-60 Khz range. Available with receive confirmation LED.	Discrete placement of infrared receiver used to control infrared capable equipment. RCV-5000 Infrared Receiver

RCV-2000/3000 Infrared Receiver - RS-232 and USB			Usage Examples
		Multi-function Infrared Receiver. Customizable for most applications. Available output and connector formats include RS-232 Serial, USB, TTL and PS-2. Infrared reception of all protocols, or, customizable to limit recognition to one or a few infrared formats or signals.	Multiple application uses. Set top box, computer control, electronic equipment, medical equipment

	RCV-2000 - Model RS-232 Serial Receiver Version
		The RCV-2000 Infrared Receiver is programmed to recognize six of the most popular infrared code protocols used in infrared remote controls: NEC, RC5, Sony, Mitsubishi. Toshiba and Matsushita. The RCV-2000 will transmit ASCII strings based on the infrared code protocol. Celadon can create custom ASCII strings mapped to specific infrared codes to meet your application requirements.	Serial computer control, set top box control, RS-232 controllable equipment.

	RCV-3000 - Model USB Receiver
		The RCV-3000 Infrared Receiver is programmed to recognize six of the most popular infrared code protocols used in infrared remote controls: NEC, RC5, Sony, Mitsubishi. Toshiba and Matsushita. The SE-USB1 will transmit ASCII strings based on the infrared code protocol. Celadon can create custom ASCII strings mapped to specific infrared codes to meet your application requirements.	Computer control, application requiring USB connection

SC-RCV-28 Infrared Receiver			Usage Examples
		Small Profile Infrared Receiver with TTL level output. Includes visible infrared signal receive LED.	Discrete placement of infrared receiver used to control infrared capable equipment.

BW TRX IRC TTL/Parallel TTL			Usage Examples
		The BW TRX IRC series uses a 38KHz carrier frequency and uses either an 8 pin direct data output or an 8 bit parallel output, depending on the transmitter model. The receiver is shipped in total knock down format and can be easily integrated into an existing design or its components can be used for a new circuit. Pre-programmed to work with the BW7070 low volume remote control.	Controlling Switches, Motors, Relays and other TTL capable devices and components. Great for volume control circuits for audio devices.
